2009 ZR1 Chevrolet Corvette - LS9 - 638 HP




2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Supercharged - 200+ MPH - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car Left side ground view shot

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car - Right rear top angle shot

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 is OUT !

This is it. The speculation, rumors and half-truths can now be set aside -- this is the 2009 Chevrolet Corvette ZR1, officially revealed for all the world to see. Powered by a supercharged LS9 6.2L small-block engine, the ZR1 hasn't even received an official horsepower number from the engineers toiling away at the General. All Harlan Charles, project manager for the Corvette team was able to tell us last week was the new high-powered 'Vette engine is "capable of producing at least 100 horsepower per liter. That's at least 620 horsepower, and approximately 595 lb.-ft. of torque." Chevrolet wasn't even able to give us a time on the 0-60. Charles was only willing to say "it's in the low three seconds." The small-block engine under the hood is only able to hit those massive numbers due to the addition of the positive-displacement Roots-type supercharger with a new, four-lobe rotor design plus an integrated charge cooling system that reduces inlet air temperature for increased performance. That's the "go" end, but the "whoa" end is just as impressive. The ZR1 gets some simply huge carbon-ceramic, drilled disc brake rotors. They're so big and are required to be so powerful they're using the same 15-inch-diameter discs found on the front of a Ferrari 599. Except on the ZR1, they go on the 20" tires in the rear. In the front, they'll be getting even larger 15.5-inch-diameter rotors, simply breathtaking to see up-close. This new Corvette used to be called the "Blue Devil", Z07, and a few other names while in the preparation stages before being announced as the ZR1 to the public.


2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car Nice shot of the carbon fiber

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car


Ride and Handling
The ZR1 is built on the same aluminum-intensive chassis as the Corvette Z06 and features similar independent SLA front and rear suspensions, with aluminum upper and lower control arms. Where the ZR1 differs is the suspension tuning, which was optimized for the car's steamroller-wide front and rear tires.
Magnetic Selective Ride Control is standard and tuned specifically for the ZR1. The system's ability to deliver a compliant ride with nearly instantaneous damping adjustments enabled engineers to develop a surprisingly supple ride quality in a supercar that still delivers cornering grip of more than 1g.
From a high-performance perspective, Magnetic Selective Ride Control helps the rear axle remain planted during launch for smooth, hop-free acceleration. It also helps suppress axle movement when cornering on broken or uneven pavement.


2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car


Exclusive Exterior
The ZR1 is instantly recognizable, with perhaps the most identifiable feature a raised, all-carbon-fiber hood that incorporates a clear, polycarbonate window. The window provides a view of the top of the engine's intercooler, with the legend "LS9 SUPERCHARGED" embossed on the left and right sides, and an engine cover with the Corvette crossed flags logo debossed at the front.
The underside of the hood has an exposed carbon-fiber-weave. Exposed carbon-fiber is used on the roof, roof bow, rocker molding and front splitter. These exterior components are protected by a specially developed glossy, UV-resistant clear coat that resists yellowing and wear.
Widened, carbon-fiber front fenders with specific, dual lower vents, and a full-width, body-color rear spoiler incorporating the center high-mounted stop lamp, are also unique to the ZR1. All of the exterior features of the car were developed to enhance high-speed stability and driver control.


2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car 220 MPH speedo

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car


With development engineer Jim Mero behind the wheel, the ZR1 paced the Nürburgring in a time of 7:26.4
This is a great video, of some awesome driving skills and an outstanding Corvette.


New, Supercharged LS9 V-8 is the Heart of the ZR1

DETROIT - Chevrolet officially announced the 2009 Corvette ZR1 - an American supercar that brings the technology and engineering refinement of carbon-fiber, ceramics and electronics together in a distinctive design.
"Chevrolet's goal with the new ZR1 is to show what an American supercar can deliver, at a price that trumps exotics that cost two, three or four times as much - and does so with exceptional drivability," said Ed Peper, Chevrolet general manager.


2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car



2009 ZR1 Chevrolet Corvette - LS9 - 638 HP - Carbon Fiber - Fast Cool Car Exploded LS9 Engine view

2009 ZR1 Chevrolet Corvette - LS9 - 620 HP - Carbon Fiber - Fast Cool Car

2009 ZR1 Chevrolet Corvette - LS9 - 638 HP - Carbon Fiber - Fast Cool Car Exploded LS9 Engine view

2009 ZR1 Chevrolet Corvette - LS9 - 638 HP - Carbon Fiber - Fast Cool Car Exploded LS9 Engine view

2009 ZR1 Chevrolet Corvette - LS9 - 638 HP - Carbon Fiber - Fast Cool Car Exploded LS9 Engine view

2009 ZR1 Chevrolet Corvette - LS9 - 638 HP - Carbon Fiber - Fast Cool Car Exploded LS9 Engine view


ZR1 Corvette - LIFE BEGINS AT 180! Miles Per Hour that is :)


More Great Pictures of the Chevrolet Supercharged LS9 - Sectionals of the Engine


By DALE JEWETT


The official dyno numbers are in: The supercharged 6.2-liter V8 in the forthcoming Chevy Corvette ZR1 cranks out 638 horsepower.

That's about 20 hp more than the estimates from General Motors' power-train gurus when they unveiled the new ZR1 and its monster motor last December.

To simplify the math: The LS9 engine in the ZR1 is rated at 103 hp per liter of displacement, or 1.7 hp per cubic inch (6.2 liters is equal to 376 cubic inches, for the old school in the audience.)

All that power will push the Corvette ZR1, which goes on sale this summer, to a top speed of more than 200 mph, GM says. A suggested retail price for the car hasn't been set, but it is expected to be in the neighborhood of $100,000.

What about the grunt? The official number is 604 lb-ft of torque.


Huge twin 300 foot burnouts, in the 638 horsepower ZR1

The key to that making all the horsepower and torque is a Roots-type supercharger with four-lobe rotors that sits atop the LS9 engine. A liquid-to-air intercooler is integrated into the supercharger's housing.

The supercharger has a volume of 2.3 liters, with a maximum boost pressure of 10.5 psi. Turning that blower required engineers to fit the LS9 with an 11-rib accessory drive belt.

The engine will be hand-built at GM's Performance Build Center in suburban Detroit, the same plant that hand-builds the LS7 V8 used in the Corvette Z06.

Time for some bench measuring, you say? OK:

-- The 6.0-liter V12 in the Ferrari 599 GTB Fiorano is rated at 620 hp and 448 lb-ft.

-- The 6.5-liter V12 in the Lamborghini Murcielago is rated at 580 hp and 650 lb-ft.

-- The turbocharged 3.6-liter flat six-cylinder engine in the Porsche 911 GT2 is rated at 530 hp and 505 lb-ft.



The ZR1's basic stats:
* All-new LS9 supercharged 6.2L V-8 targeted at producing at least 100 horsepower per liter, or 620 horsepower (462 kW), and approximately 595 lb.-ft. of torque (823 Nm)
* Six-speed, close-ratio, race-hardened manual transmission
* New, high-capacity dual-disc clutch
* Higher-capacity and specific-diameter axle half-shafts; enhanced torque tube
* Specific suspension tuning provides more than 1g cornering grip
* Twenty-spoke 19-inch front and 20-inch rear wheels
* Michelin Pilot Sport 2 tires - P285/30ZR19 in front and P335/25ZR20 in the rear - developed specifically for the ZR1
* Standard carbon-ceramic, drilled disc brake rotors - 15.5-inch-diameter (394-mm) in the front and 15-inch-diameter (380-mm) in the rear
* Larger brake calipers with substantially increased pad area
* Standard Magnetic Selective Ride Control with track-level suspension
* Wider, carbon-fiber front fenders with ZR1-specific dual vents
* Carbon-fiber hood with a raised, polycarbonate window - offering a view of the intercooler below it
* Carbon-fiber roof panel, roof bow, front fascia splitter and rocker moldings with clear-coated, exposed carbon-fiber weave
* ZR1-specific full-width rear spoiler with raised outboard sections
* Specific gauge cluster with boost gauge (also displayed on the head-up display) and 220-mph (370 km/h) speedometer readout
* Only two options: chrome wheels and a "luxury" package
* Curb weight of approximately 3,350 pounds (1,519 kg)

The specialized components of the new ZR1 work harmoniously to deliver the most powerful and fastest automobile ever produced by General Motors. Performance estimates will be announced closer to vehicle's summer 2008 launch.
"Preliminary testing shows the ZR1 builds on the highly respected Corvette Z06 in every performance category, from acceleration and braking, to cornering grip and top speed," said Peper. "It all boils down to the power-to-weight ratio and the ZR1's is exceptional - better than the Porsche 911 GT2, the Ferrari 599 and even the Lamborghini LP640. In fact, the ZR1 is expected to be the first production Corvette to achieve a top speed of at least 200 mph."
2009 Chevrolet ZR1 Corvette - Jake 620HP factory superchargedSupercharged LS9 Engine
The new LS9 6.2L small-block engine is the power plant the supports the ZR1's performance capability. The enabler of the LS9's performance and refinement is a large, positive-displacement Roots-type supercharger with a new, four-lobe rotor design. It is augmented with an integrated charge cooling system that reduces inlet air temperature for maximum performance.

A sixth-generation supercharger developed by Eaton helps the LS9 make big power and torque at lower rpm and carries it in a wide arc to 6,600 rpm, as it pushes enough air to help the engine maintain power through the upper levels of the rpm band - the area where supercharged performance tends to diminish. Heavy-duty and lightweight reciprocating components enable the engine's confident high-rpm performance.
The LS9 is hand-assembled at GM's Performance Build Center, in Wixom, Mich., and incorporates specialty processes typically seen in racing engines to produce a highly refined and precise product. For example, cast iron cylinder liners are inserted in the aluminum block and are finish-bored and honed with a deck plate installed. The deck plate simulates the pressure and minute dimensional variances applied to the block when the cylinder heads are installed, ensuring a higher degree of accuracy that promotes maximum cylinder head sealing, piston ring fit and overall engine performance.

Transmission and Axle
The LS9 engine is backed by a new, stronger six-speed manual transmission and a twin-disc clutch that provide exceptional clamping power, while maintaining an easy clutch effort. ZR1-specific gearing in the transmission provides a steep first-gear ratio that helps launch the car, and top speed is achieved in sixth gear - a change from the fifth-gear top-speed run-outs in the manual-transmission Corvette and Corvette Z06.
As the term implies, the twin-disc clutch system employs a pair of discs, which spreads out the engine's torque load over a wider area. This enables tremendous clamping power when the clutch is engaged, while also helping to dissipate heat better and extend the life of the clutch.
The twin-disc clutch system also contributes to the ZR1's exceptional driving quality, with smooth and easy shifting. The twin-disc system's design enables a 25-percent reduction in inertia, thanks to smaller, 260-mm plates, corresponding to a pedal effort that is similar to the Corvette Z06's 290-mm single-disc system.
The rear axle also is stronger in the ZR1 and features asymmetrical axle-shaft diameters that were developed after careful testing to provide optimal torque management. The axles are also mounted on a more horizontal plane that correlates with the wider width of the rear wheels and tires.
2009 Chevrolet ZR1 Corvette - Jake - Blown ZR1, hello 200+ MPH from your local Chevrolet DealershipBrakes, Wheels and Tires
Commensurate with the ZR1's engine output is the braking system, which is headlined by carbon-ceramic brake rotors. Found on only a few exotics and more expensive supercars, carbon-ceramic brake rotors are made of a carbon-fiber-reinforced ceramic silicon carbide material . Their advantage comes in low mass and resistance to wear and heat. In fact, the rotors should never show any corrosion or require replacement for the life of the vehicle, when used in normal driving.
The vented and cross-drilled rotors on the ZR1 measure 15.5 inches (394 mm) in diameter in the front and 15 inches (380 mm) in diameter in the rear - making them among the largest carbon-ceramic rotors available on any production vehicle.
Clamping down on the high-tech rotors are six-piston front calipers and four-piston rear calipers, each painted a ZR1-exclusive blue. The front pads are equivalent in size to the largest on any production car with a single-pad design - double that of the Corvette Z06's 70-sq.-cm. front pads.
The brakes are visible through the ZR1's exclusive wheels: 20-spoke alloy rims that measure 19 inches in diameter in the front and 20 inches in the rear. They come standard with a bright, Sterling Silver paint finish and chrome versions are optional. The wheels are wrapped in Michelin Pilot Sport 2 tires developed specifically for the ZR1, measuring P285/30ZR19 in front and P335/25ZR20 in the rear.

Interior Details
The ZR1's interior builds on the brand's dual-cockpit heritage, with high-quality materials, craftsmanship and functionality that support the premium-quality experience promised by the car's performance. The ZR1's cabin differs from the Corvette and Corvette Z06 with the following:
* ZR1-logo sill plates
* ZR1-logo headrest embroidery
* Specific gauge cluster with "ZR1" logo on the tachometer and a 220-mph (370 km/h) readout on the speedometer
* Boost gauge added to the instrument cluster and Head-Up Display
The "base" ZR1 (RPO 1LZ) comes with accoutrements based on the Z06, including lightweight seats and lightweight content. The uplevel interior package includes unique, power-adjustable and leather-trimmed sport seats (embroidered with the ZR1 logo); custom, leather-wrapped interior available in four colors; navigation system, Bluetooth connectivity and more.
2009 Chevrolet ZR1 Corvette - JakeBy the Numbers
In addition to the exterior cues and powertrain, ZR1 models will be distinguished from other Corvette models by their VIN. Each will carry a unique, identifying VIN digit, as well as a sequential build number. This makes it easy to determine the build number of a specific car - information treasured by enthusiasts and collectors. For example, a ZR1 with a VIN ending in "0150" would indicate it is the 150 th ZR1 built for the model year

Boasting a 620-plus horsepower V8 and a price expected around $100,000, the 2009 Corvette ZR1 is the result of General Motors Corp. chairman Rick Wagoner’s challenge to build the ultimate Corvette.

The ZR1 aims to match the performance of supercars like the 612-horsepower $273,845 Ferrari 599 GTB Fiorano F1 coupe, which accelerates to 62 m.p.h. in 3.7 seconds.

“Our goal with the ZR1 is to show that an American supercar can deliver performance that beats exotics that cost two, three or four times as much,” Chevrolet general manager Ed Peper said.

Chevrolet hasn’t announced the exact price for the 2009 ZR1, but the supercar was born when Wagoner asked the Corvette team to show him what it could accomplish with a $100,000 Corvette.

Within GM, the secret project was referred to as the Blue Devil, ,” a reference to the mascot for athletic teams at Wagoner’s alma mater, Duke University. The super-Vette features a supercharged 6.2-liter version of GM’s legendary small-block V8 engine, extensive use of lightweight carbon-fiber body panels and a host of other performance upgrades.

Chevrolet hasn’t revealed performance figures yet, but the ZR1 will have a top speed in excess of 200 m.p.h. and will be able to race from zero to 60 m.p.h. in first gear.

“The Corvette is really a brand unto itself,” said Michelle Krebs, editor of AutoObserver.com. “The ZR1 is a logical extension of that.”

The hand-built engines will come from GM’s performance-build center in Wixom. The Corvette plant in Bowling Green, Ky., will build the car.

The ZR1 will be recognizable on the street thanks to a clear panel in the hood that provides a view of the engine, a unique, clear-coated carbon-fiber roof and other changes that include massive disc brakes with a unique shade of blue used only on the ZR1.

It took years to develop the clearcoat for the carbon-fiber because sunlight degrades the material over time. The coating, which only the ZR1 has, uses a special additive to prevent that. The additive alone costs $60,000 a gallon, while the mixture of clearcoat and additive applied to the roof costs $2,200 a gallon.

The fastest, most powerful and most expensive Chevrolet Corvette ever will roar to life at the North American International Auto Show in Detroit next month.

For the time being everyone else will have to enjoy the gallery above.
